casting steel flange float ball valve dn125

Model: JY163
Place of Origin: Zhejiang,China (Mainland)
Power: Manual
Standard or Nonstandard: Standard
Pressure: Low Pressure
Structure: Ball
Material: Stainless Steel
Temperature of Media: Normal Temperature
Media: Water
Brand Name: JY/OEM
Port Size: Standard
Application: valve
Seal material: EPDM
Valve body: Ball valve
Disc: stainless steel, copper
Rotation angle: 0-90°
Weight: depens on differenct size
Product name: casting steel flange float ball valve dn125
Actuator Installation angle: any angle
  video

inquiry

basketAdd to Basket  Edit

Share |

Product Description

Payment & Shipping Terms Supply Capacity
Unit Price:1.5 USDProduction Capacity:32000 Set/Sets per...
Trade Term:FOB,CFR,CIF,EXWPacking:Valves are wrapped in...
Payment Terms:L/C, WU, D/P, T/TDelivery Date:stock or 15 days
Min. Order:1 Pack/Packs
Means of Transport:Land, Ocean, Air

casting steel flange float ball valve dn125


Description of Product


Feature of flange float ball valve dn125:

flange float ball valve dn125 for chilled wateradopts lever operation, the valve adopts stainless steel 301, 304, 316, 316L material such as production and processing, quality is reliable and trustworthy. Stainless steel flange ball valve has a stainless steel flange floating ball valve, stainless steel flange fixed ball valve, stainless steel flange three way ball valve, stainless steel flange insulation ball valve etc. series, the product belongs to the series of floating ball.



Materials of major parts:

Valve bodyZG1Cr18Ni9TiCF8CF3ZG1Cr18Ni12Mo2TiCF8MCF3M
Ball, Stem1Cr18Ni9Ti304304L1Cr18Ni12Mo2Ti316316L
SeatPTFE, PTFE+Glass, PPL
GasketPTFE, Stainless steel / flexible graphite
Stem SeatPTFE, Stainless steel / flexible graphite
PackingPTFE, Enhanced Flexibie Graphite
Packing Gland1Cr18Ni9Ti304304L1Cr18Ni12Mo2Ti316316L
Temperature -29~150(PTFE), -29~200( PTFE+GLASS), -29~300(J2 PPL)




Performance specification:

ModelNominal Test pressureWorking
Strength Seal Air Low pressure seal
pressure(water)Mpa(water)(Mpa)(Air )MpaTemperature(℃)
Q41F-16R(P)1.62.41.80.6≤150
Q41F-25R(P)2.53.82.80.6≤150
Q41F-40R(P)464.40.6≤150



Machining Process


Work Shop



Why Choose US


We control the material of PTFE(Teflon) and stainless steel wires per customer's request.

Some are from Japan and Taiwan, some are from China local. Only choose high quality material.

We test leakage of each roll before braiding, then we cut 300mm and crimp it to test

burst pressure after brading.

We use CNC Lathes Machine for end fittings production. Machine system, knife and inspection

tools are all imported from Japan.

We use Techmaflex Crimping Machine which is imported from France. This machine has

accurate and stable performance for crimping because it is produced for PTFE hose crimping only.
