good material made in china freon gauge pressure

Model: JY1726
Place of Origin: Zhejiang,China (Mainland)
Brand Name: JUYUAN
Place of Origin: Zhejiang, China (Mainland)
Brand Name: OEM
Item name: Promotional Water Well Pressur
Quality: 100% Inspection
Pressure range: -30inHg-0, 0 up to 25,000 psi
Dial size: 1.5" , 2", 2.5", 3", 4" , 4.5", 6", 8", 10
Connection: 1/8", 1/4", 3/8", 1/2"
Mounting: Bottom,back and panel
Advantage: Factory(can be customized)
Wetted parts: Stainless Steel

inquiry

basketAdd to Basket  Edit

Share |

Product Description

Payment & Shipping Terms Supply Capacity
Unit Price:0.1 USDProduction Capacity:200000 Meter Per...
Trade Term:FOB,CFR,CIF,DDP,DAP,CIP,CPT,FCA,EXWPacking:Plastic woven...
Payment Terms:Paypal, L/C, T/T, WU, Money GramDelivery Date:Shipped in 30 days...
Min. Order:1 Piece/Pieces
Means of Transport:Ocean, Air, Land

good material made in china freon gauge pressure absolute



Description

Dial diameter

2½" - FL series and F-BD series

2¾" - F-A series

Mounting types

Type A --bottom connection

Type BD - back connection with flange

Case

FL series-stainless steel, crimp bezel

F-A series-steel or plastic (red / blue)

F-BD series-steel (with plating or black enamel)

Lens

Plastic

Measuring principle

Bourdon Tube, bronze

Movement

Brass

Connection

Bottom connection – 1/8"NPT male thread

Back connection – 7/16"UNF (1/4"SAE) male thread

Filling

Glycerin, only available for FL series

Adjustment

Adjustment screw on the dial, only available for F series

Accuracy

±2.5% F.S.

Scale

R12, R22, R502;R134A;R404A;R410A

Kg/cm2;bar;psi;kPa;℃;℉

Ranges

R12, R22, R502:-30inHg / 0 / 250psi & 0 / 500 psi

R134A:-30inHg / 0 / 250psi & 0 / 500 psi

R404A:-30inHg / 0 / 250psi & 0 / 500 psi

R410A:-30inHg / 0 / 500psi & 0 / 800 psi

Accessory

(option)

Protective gauge boots ( blue / red)

Only available for F-A series

Application

All kinds of refrigeration systems, for example, air-conditioner  and freon charging equipment.







Producing


Packing


Certificate

Sale and Market




Why choose us

We control the material of PTFE(Teflon) and stainless steel wires per customer's request.

Some are from Japan and Taiwan, some are from China local. Only choose high quality material.

We test leakage of each roll before braiding, then we cut 300mm and crimp it to test

burst pressure after brading.

We use CNC Lathes Machine for end fittings production. Machine system, knife and inspection

tools are all imported from Japan.

We use Techmaflex Crimping Machine which is imported from France. This machine has

accurate and stable performance for crimping because it is produced for PTFE hose crimping only.
