wholesale cast iron 90 degree 2pc ball valve

Model: JY155
Place of Origin: Zhejiang,China (Mainland)
Power: Others
Standard or Nonstandard: Standard
Pressure: Low Pressure
Structure: Ball
Material: Stainless Steel
Temperature of Media: Normal Temperature
Media: Water
Brand Name: JY/OEM
Port Size: Standard
Application: valve
Seal material: EPDM
Valve body: Ball valve
Actuator: FOSD series
Disc: stainless steel, copper
Rotation angle: 0-90°
Weight: depens on differenct size
Actuator Power: AC24V, AC110V, AC220V, AC380V, DC12V DC24V all is customized


basketAdd to Basket  Edit

Share |

Product Description

Payment & Shipping Terms Supply Capacity
Unit Price:1.5 USDProduction Capacity:32000 Set/Sets per...
Trade Term:FOB,CFR,CIF,EXWPacking:Valves are wrapped in...
Payment Terms:L/C, D/P, T/T, WUDelivery Date:stock or 15 days
Min. Order:1 Piece/Pieces
Means of Transport:Ocean, Air, Land

wholesale cast iron 90 degree 2pc ball valve

Description of Product

Feature of ball valve:

   The ball valve is a form of quarter-turn valve which uses a hollow, perforated and pivoting ball (called a "floating ball")

to control flow through it. It is open when the ball's hole is in line with the flow and closed when it is pivoted 90-degrees

by the valve handle, The handle lies flat in alignment with the flow when open, and is perpendicular to it when closed,

making for easy visual confirmation of the valve's status.


  Our Ball valves are durable, performing well after many cycles, and reliable, closing securely even after long periods

of disuse. these qualities make them an excellent choice for shut/off application,  Our ball valve's ease of operation,

repair, and versatility lend it to extensive industrial use, supporting pressures up to 1000 bar and temperatures up to

752°F (500°C), depending on design and materials use.


We have two pieces and three pieces ball valve design, available for customers, this type ball valve are available from

DN15 to DN200,  Our elelctric actuator can match different sizes ball velve no matter you require shut/off or

regulating function, material could be WCB, Stainless steel 304, CF8, A744.


Besides this flange ball valve, we also have thread ball valve, including soft seal ball valve, hard seal ball valve.

Valve actuator Specification for ball valve

Output torque 50Nm100Nm160Nm300Nm600Nm1250Nm2500Nm4000Nm
Rated travel time20S15S/30S30S/60S100S100S100S
Rotation angle0°-90°0°-90°0°-90°0°-90°0°-90°0°-90°0°-90°0°-90°
Working current 0.25A0.48A0.68A0.8A1.2A2A2A2.7A
Starting power 0.25A0.48A0.72A0.86A1.38A2.3A2.3A3A
Motor power 10W/F25W/F30W/F40W/F90W/F100W/F120W/F140W/F
Power AV220V,       AC24V,     AC110V ,    AV220 ,       AC380,      DC24V (choose options)
Insulation resistance100M/500VDC
Pressure withstanding1500 VAC ,   one minutes
Inbreaking protection IP65/IP67
Installation angle360° any angle
Electrical Interperationone G1/2 CNCO,one Power cord connection port,one signal wire connection port
Ambient humidity             -30°C  to +60°C
Pilot circuit options
A:with limit position switch style (standard)
B: with neutral position switch style ( passive contact)
C:with potentiometer style
D: both potentiometer and neutral position switch style
E: with control module style ( Modulating Applications)
F: DC motor control circuit style
G:Three-phase current 380V control circuits style
H:Three-phase current 380V, both neutral position switch and potentiometer style

Machining Process

Work Shop

Other Product

Why Choose US

We control the material of PTFE(Teflon) and stainless steel wires per customer's request.

Some are from Japan and Taiwan, some are from China local. Only choose high quality material.

We test leakage of each roll before braiding, then we cut 300mm and crimp it to test

burst pressure after brading.

We use CNC Lathes Machine for end fittings production. Machine system, knife and inspection

tools are all imported from Japan.

We use Techmaflex Crimping Machine which is imported from France. This machine has

accurate and stable performance for crimping because it is produced for PTFE hose crimping only.
