| Min. Order: | 500 Piece/Pieces |
|---|---|
| Trade Term: | FOB,FCA |
| Payment Terms: | Paypal, L/C, D/P, D/A, T/T, WU |
| Place of Origin: | Zhejiang, China (Mainland) |
| Means of Transport: | Ocean, Air, Land |
| Production Capacity: | 10 0000pcs per month |
| Packing: | Polybag, Inner Box,... |
| Delivery Date: | Shipped in 30 days... | Power: | Manual |
|---|---|---|---|
| Standard or Nonstandard: | Standard | Media: | Water |
| Pressure: | Medium Pressure | Material: | Stainless Steel |
| Temperature of Media: | Normal Temperature | Structure: | Check |
| Brand Name: | JUNYUAN | Size: | 1/2", 3/8", 1/2" |
| Thread Connection: | Female Thread,BSP.NPT | Technical: | FORGED |
| Certificate: | ISO9001, CE,ACS.UL,CSA | Brand: | JY or Professional OEM |
| Working Temperature: | -10-110℃ | HS Code: | 8481804090 |
| Function: | water ,oil ,Steam |
- End connections avail be with AFK tube end , BSPT or NPT female & male thread for option
- Inline check valve stops reversed flow in order to protect instrumentation
- Body material in Stainless Steel SS316/316L Cold drawn bar
- Max. allowed working pressure 3000psi (206 bar)
- 100% tested
Specifications
Dimensions(inch) | ||||
Size | A-PT/NPT/G | B-PT/NPT/G | C-(mm) | D(mm) |
1/8" | 1/8" | 1/8" | 19 | 74 |
1/4" | 1/4" | 1/4" | 19 | 74 |
3/8" | 3/8" | 3/8" | 22 | 74 |
1/2" | 1/2" | 1/2" | 27 | 75.5 |
3/4" | 3/4" | 3/4" | 35 | 83.5 |
1" | 1" | 1" | 41 | 87.5 |
Can be customized according to customer's' requirements | ||||
