| Min. Order: | 50 Piece/Pieces |
|---|---|
| Trade Term: | FOB |
| Payment Terms: | Paypal, L/C, D/P, D/A, T/T, WU, Money Gram |
| Place of Origin: | Zhejiang, China (Mainland) |
| Means of Transport: | Ocean, Air, Land |
| Production Capacity: | 120000 PCS Per month |
| Packing: | white box corrugated... |
| Delivery Date: | Shipped in 30 days... | Power: | Manual |
|---|---|---|---|
| Standard or Nonstandard: | Standard | Media: | Water |
| Pressure: | Medium Pressure | Material: | Bronze,Brass |
| Temperature of Media: | Medium Temperature | Structure: | Check |
| Brand Name: | OEM | Certificate: | ISO9001 ,CE |
| Size:: | DN15-DN65 | Sealings:: | NBR, EPDM, Viton, PTFE envelop gasket |
| Color:: | Copper | Head Code: | round or Square |
| Connector type: | BSP(BSPP),BSPT,NPT | HS code: | 7609000000 |
| Technics:: | Casting,gravity casting. | Brand Name:: | JY or OEM |
Part No. | Material |
1 - Body | Bronze |
2 - Bonnet | Bronze |
3 - Disc | Bronze |
4 - Stem | Brass |
SIZE | d | L1 | C | D | n-h | t | Globe (Kg) | Check(Kg) |
015 | 15 | 110 | 70 | 95 | 4-15 | 12 | 2.76 | 2.70 |
020 | 20 | 120 | 75 | 100 | 4-15 | 14 | 3.72 | 3.63 |
| 025 | 25 | 130 | 90 | 125 | 4-19 | 14 | 5.20 | 5.09 |
032 | 32 | 160 | 100 | 135 | 4-19 | 16 | 6.91 | 6.77 |
| 040 | 40 | 180 | 105 | 140 | 4-19 | 16 | 8.43 | 8.25 |
Category: MARINE VALVES
